Hypertrophic cardiomyopathy is the most frequently occurring inherited cardiovascular disease, with a prevalence of more than one in 500 individuals worldwide. Genetically acquired dilated cardiomyopathy is a related disease that is less prevalent. Both are caused by mutations in the genes encoding the fundamental force-generating protein machinery of the cardiac muscle sarcomere, including human β-cardiac myosin, the motor protein that powers ventricular contraction. Despite numerous studies, most performed with non-human or non-cardiac myosin, there is no clear consensus about the mechanism of action of these mutations on the function of human β-cardiac myosin. We are using a recombinantly expressed human β-cardiac myosin motor domain along with conventional and new methodologies to characterize the forces and velocities of the mutant myosins compared with wild type. Our studies are extending beyond myosin interactions with pure actin filaments to include the interaction of myosin with regulated actin filaments containing tropomyosin and troponin, the roles of regulatory light chain phosphorylation on the functions of the system, and the possible roles of myosin binding protein-C and titin, important regulatory components of both cardiac and skeletal muscles.
Dozens of laboratories, working over the course of more than a century and using a wide variety of approaches, have contributed importantly to our understanding of muscle contraction (Rall, 2014). The muscle sarcomere may well be the most studied protein complex in cell biology, partially due to its extraordinarily high degree of structural organization.
I (J.A.S.) was asked to preface my talk at the 2015 Journal of Experimental Biology Symposium on Muscle: Molecules to Motion with a brief historical perspective of my laboratory's specific contributions to research on actin and myosin, and how those contributions led to our current focus on understanding the molecular basis of hypertrophic and dilated cardiomyopathy. My laboratory, over the last several decades, has been devoted to developing both in vivo and in vitro systems to understand the molecular basis of energy transduction by the myosin family of molecular motors (Spudich, 2011, 2012). Our interests have included the roles of myosins in non-muscle cells and the molecular basis of muscle contraction. Essential for our research was the development of in vitro motility assays for purified actin and myosin in the 1980s (Kron and Spudich, 1986; Spudich et al., 1985). We used these assays to show that the globular head of myosin, known as subfragment-1 (S1), is the motor domain of the myosin molecule (Toyoshima et al., 1987), and, together with molecular genetic approaches, we provided early strong functional evidence that the light-chain binding region of the S1 acts as a swinging lever arm during chemo-mechanical coupling (e.g. Shih et al., 2000; Uyeda et al., 1996). Our study on changing the lever arm length and even removing the light-chain binding region altogether was an early work that showed that the heavy chain, truncated after the converter domain (Fig. 1, myosin head structure on the right), is the ‘motor domain’ of the molecule, and the lever arm amplifies allosteric movements in the motor domain to obtain a larger stroke size – the distance myosin moves an actin filament per ATP hydrolyzed (Uyeda et al., 1996). Using the physics of laser trapping, we simplified the motility assay to the single molecule level, which allowed the measurement of the stroke size (∼10 nm) as well as the intrinsic force produced by the motor (a few piconewtons) (Finer et al., 1994). With these tools in hand, and after studying a variety of myosin motor types over several decades, my laboratory is now fully focused on one of the most clinically important members of the myosin family of molecular motors, human β-cardiac myosin.
Human cardiomyopathy mutations are a leading cause of cardiac death
The human β-cardiac myosin motor is a major site in the sarcomere for hundreds of missense mutations that result in a spectrum of heart diseases called cardiomyopathies. Genetically based hypertrophic cardiomyopathy (HCM), an autosomal dominant inherited disease (Geisterfer-Lowrance et al., 1990; Seidman and Seidman, 2000, 2001), is clinically characterized by thickening of the ventricular walls with a resultant decrease in ventricular chamber size that occurs without a predisposing cause. Systolic performance of the heart is preserved or even increased, but relaxation capacity is diminished. HCM affects more than one in 500 individuals (Harvey and Leinwand, 2011; Maron, 2011; Maron et al., 1995; Semsarian et al., 2015). Dilated cardiomyopathy (DCM), in contrast, is characterized by thinning of the heart walls, enlargement of the ventricular chambers, and weakness of the cardiac muscle, resulting in an inability to raise the cardiac output to meet the demands of even modest exercise (Hershberger et al., 2013).
There are reported to be more than 300 pathogenic mutations in β-cardiac myosin (Buvoli et al., 2008; Colegrave and Peckham, 2014; Seidman and Seidman, 2001; Walsh et al., 2010). Most of these are HCM mutations in the globular head domain, myosin S1 (Colegrave and Peckham, 2014). The other major site in the sarcomere for HCM-causing mutations is a regulatory protein known as myosin binding protein-C (MyBP-C). MyBP-C is thought to put a break on the contraction of the muscle, which can be regulated by its phosphorylation (Chow et al., 2014; Kensler et al., 2011; Seidman and Seidman, 2000; van Dijk et al., 2014). A smaller but significant set of mutations are found in the tropomyosin–troponin complex. Tropomyosin (Tm) and the three troponin subunits, troponin T (TnT), troponin I (TnI), and troponin C (TnC), form the Ca2+-regulatory complex of the sarcomere. The actin, myosin, tropomyosin, and the three troponins constitute a six-component system that is considered to be the fundamental regulated contractile complex of the sarcomere (Fig. 2). MyBP-C, which is in the vicinity of the myosin heads in the sarcomere, should be added as a seventh component of the fundamental regulated complex. Furthermore, the giant protein titin is also in the vicinity of the myosin heads in the sarcomere and has been shown to carry DCM mutations (Gerull et al., 2002; Herman et al., 2012; LeWinter and Granzier, 2013, 2014).
essential light chain
myosin binding protein-C
total number of functionally available heads
regulatory light chain
total cycle time
strongly bound state time
Much more is known about the role of the Tm.Tn regulatory complex in cardiac contraction than that of the regulatory proteins MyBP-C and titin. There is good evidence that domains of MyBP-C near the N terminus bind to the regulated actin filament while its C terminus binds to the myosin thick filament backbone (Fig. 2), thus playing a regulatory role in muscle contraction (Chow et al., 2014; Kensler et al., 2011; van Dijk et al., 2014). Studies also suggest that MyBP-C binds to myosin S2, the coiled-coil domain just C-terminal to the globular S1 head, as well as to the regulatory light chain (RLC) of the myosin S1 (Harris et al., 2004; Kampourakis et al., 2014; Pfuhl and Gautel, 2012; Ratti et al., 2011). Titin has been thought of as an element involved in passive tension in the sarcomere (Granzier and Irving, 1995), but as discussed below, MyBP-C and titin may both contribute importantly to the regulation of ensemble force production by the myosin.
The force–velocity curve is fundamental to muscle contraction
As described above, clinically HCM mutations are associated with hypercontractility, whereas DCM mutations are associated with hypocontractility. This has led to the general hypothesis that HCM mutations are hypercontractile and DCM mutations are hypocontractile at the fundamental molecular level. Many important studies have contributed to our current understanding of the effects of some HCM and DCM mutations on various functions of the purified actomyosin complex, usually its ATPase activity or its velocity in the in vitro motility assay (for review, see Moore et al., 2012; Sivaramakrishnan et al., 2009). Only a few studies have attempted to explore the effects of the mutations on the power output generated by a reconstituted actin–myosin complex (Aksel et al., 2015; Debold et al., 2007; Greenberg et al., 2010; Sommese et al., 2013b). Ultimately, the molecular basis of changes in power output is what one needs to understand.
Power (P) output comes directly from the force–velocity (F–V) curve of muscle contraction, as P=F×v (Fig. 3). The force axis on this curve is related to the load on the muscle; the force the muscle produces must overcome the load. Ventricular function is influenced by the two types of loads that are applied to cardiac muscle. One is preload, the load applied by the volume of blood filling the left ventricle that results in stretching of the myofibrils prior to the initiation of ejection. The other is afterload, the load due to pressure in the systemic circulation during contraction when the aortic valve is open. The afterload is the primary load that the heart needs to overcome to eject blood out of the left ventricle.
A somewhat oversimplified but useful view of velocity (v) and ensemble force (Fensemble) breaks these down into five parameters, f, d, ts, tc, and Nt (Fig. 3). The velocity at any load is a reflection of d/ts, the distance moved per strongly-bound state time of the motor to actin. Fensemble is the intrinsic force f of each motor domain multiplied by the total number of myosin heads in a force-producing state at any moment. The latter is the total number of heads functionally available (Nt) times the duty ratio. The duty ratio for those heads available to interact with the actin is ts/tc, where ts is the strongly bound state time of myosin on the actin at a particular load and tc is the total cycle time of the actin-activated myosin chemomechanical cycle. The weakly bound states of the motor are the ATP- and ADP-Pi-bound states, while the strongly bound states are the ADP-bound states (Fig. 4). Thus the ensemble force in the sarcomere is Fensemble=f(ts/tc)Nt.
We have been examining these individual parameters for several myosin HCM and DCM mutations studied in a recombinant form of human β-cardiac myosin (short S1 or sS1) that consists of residues 1–808 (the motor domain elongated by the essential light chain [ELC] binding domain) co-expressed with the human cardiac ventricular ELC (MYL3) (Fig. 1, second myosin head image).
Changes in intrinsic force, cycle time and strongly bound state time are generally small for HCM and DCM mutations
Although several-fold changes in intrinsic force, cycle time or strongly bound state time have been reported in studies of HCM and DCM using non-human myosins compared with wild type (WT), we have found only small (10–50%) changes in any of these parameters for the HCM mutant forms we have studied using the human β-cardiac sS1 (R403Q, R453C, R719W, R723G, and R663H). In general, these relatively small changes are not surprising, as most patients with HCM do not begin to exhibit symptoms until at least the third decade of life (and often much later).
The DCM mutants (I201T, A223T, R237W, S532P, and F764L) showed somewhat larger changes compared with WT than the HCM mutants. M531R, a left ventricular non-compaction mutant, showed the largest change, the tc of which was decreased 1.7-fold compared with WT (Aksel et al., 2015).
In general, we are finding that the DCM mutations all behave similarly; for example, they all increase tc. In contrast, the HCM mutations are variable, some appearing more hypocontractile with regard to these parameters and others slightly hypercontractile. These variabilities led us to develop a metric that relates to Fensemble more directly, using a loaded in vitro motility assay.
An ensemble force metric derived from a loaded in vitro motility assay
One way to measure actin gliding velocities at different loads is using a loaded in vitro motility assay in which increasing concentrations of an actin binding protein is utilized as the load-bearing molecule (Bing et al., 2000; Greenberg and Moore, 2010; Haeberle and Hemric, 1995; Warshaw et al., 1990). This assay has been used to compare power output and maximal force generation between myosin variants (Greenberg et al., 2010; Haeberle, 1994; Malmqvist et al., 2004) and between different solution conditions (Greenberg and Moore, 2010; Janson et al., 1992). The load-bearing molecule often used is α-actinin.
The α-actinin assay does not work well, however, with the small motor domain sS1, presumably because of the small size of this domain compared with that of two-headed myosin constructs (Aksel et al., 2015). To obtain information about the relative ensemble forces of mutant and WT human β-cardiac sS1, we developed an utrophin-based loaded in vitro motility assay (Aksel et al., 2015) (Fig. 5A). The actin-binding protein utrophin is used to put a load on the actin filaments that the myosin must overcome. To achieve proper control of myosin and load molecule ratios, a truncated utrophin construct of similar size to sS1 is engineered to anchor on a glass surface via the same attachment used for sS1. Both the velocity of the filaments and the percentage of mobile filaments decrease as utrophin concentration is increased. These two parameters can be combined into what we call the percent time mobile (Fig. 5B). This parameter is a proxy for the ensemble force generated by the motor molecule (Aksel et al., 2015). Importantly, to facilitate these experiments, we also developed a rapid, objective filament-tracking software called FAST (Aksel et al., 2015). (For details of the FAST classes and routines, see the FAST package available at http://spudlab.stanford.edu/fast-for-automatic-motility-measurements/. FAST is currently available for both Linux [Ubuntu 14.04] and Mac operating systems. Academic license for FAST is available for free on http://spudlab.stanford.edu/fast-for-automatic-motility-measurements/.)
We have used the utrophin loaded motility assay and FAST to characterize human α- and β-cardiac sS1 (Aksel et al., 2015). As seen in Fig. 5B, the amount of utrophin needed to overcome the motility of human α-cardiac sS1 is considerably less than that needed to overcome the human β-cardiac sS1, consistent with α-cardiac sS1 being a weaker motor (producing less Fensemble) than β-cardiac sS1 (Malmqvist et al., 2004). We have also applied this approach to mutants that show opposite mechanical and enzymatic phenotypes with respect to each other, the hypercontractile left ventricular non-compaction mutant M531R and the hypocontractile DCM mutant S532P (Aksel et al., 2015). By this test, M531R is a stronger motor than WT, while S532P is a weaker motor. We also showed that omecamtiv mecarbil, a previously discovered cardiac specific myosin activator (Malik et al., 2011), increases β-cardiac sS1 Fensemble generation as judged by this loaded in vitro motility assay (Aksel et al., 2015). We are now applying this approach to more than 15 cardiomyopathy mutant forms of human β-cardiac sS1.
HCM and DCM mutations in the tropomyosin–troponin complex are Ca2+-sensitizing and Ca2+-desensitizing, respectively
The tropomyosin–troponin complex is the Ca2+ sensor in the muscle and is composed of tropomyosin and three troponin subunits: (1) TnC, which binds Ca2+; (2) TnI, which binds actin and tropomyosin and is the inhibitory subunit; and (3) TnT, which binds tropomyosin and communicates the Ca2+ signal from TnC to tropomyosin (Brown and Cohen, 2005; Kobayashi and Solaro, 2005). In the absence of Ca2+, tropomyosin is in a position along the actin filament that blocks the binding of myosin. Upon Ca2+ binding to TnC, the inhibitory region of TnI dissociates from tropomyosin, allowing the tropomyosin to move azimuthally on the actin filament, revealing the myosin binding sites on actin. Mutations in these proteins have been studied using various methods, including: animal models, skinned fibers into which mutant proteins have been exchanged, and reconstituted in vitro molecular studies using endogenous and/or recombinant proteins such as ATPase, fluorescence, and motility assays (e.g. Miller et al., 2001; Mirza et al., 2005).
Extensive studies by many investigators have yielded important advances in understanding the effects of HCM- and DCM-causing mutations on a reconstituted six-component system consisting of actin, myosin, tropomyosin, and the three troponin subunits (for reviews, see Hitchcock-DeGregori, 2008; Kobayashi and Solaro, 2005; Moss et al., 2004; Tardiff, 2011; Willott et al., 2010). Most biochemical thin filament studies have been performed using non-human cardiac myosin (e.g. Szczesna et al., 2000; Venkatraman et al., 2005, 2003) or skeletal myosin (e.g. Kobayashi et al., 2013; Lin et al., 1996; Mirza et al., 2005; Tobacman et al., 1999). More recent studies have used human β-cardiac myosin, where some specific differences in biochemical parameters were found compared with earlier non-human myosin studies (Bloemink et al., 2014; Deacon et al., 2012; Gupte et al., 2015; Sommese et al., 2013b). Regardless of the source of the mammalian myosin, however, the general paradigm holds true that HCM mutations in tropomyosin or troponin are sensitizers to Ca2+ (e.g. Fig. 6 shows HCM mutations for three TnI mutations), while DCM mutations are desensitizers (Willott et al., 2010).
The myosin mesa and a possible role for MyBP-C and titin in regulating the number of functionally available myosin heads in the sarcomere
Besides β-cardiac myosin, the other major site in the sarcomere for HCM mutations is the regulatory protein MyBP-C (Buvoli et al., 2008; Seidman and Seidman, 2011; Walsh et al., 2010). MyBP-C is thought to put a break on the contraction of the muscle, which can be regulated by its phosphorylation (Chow et al., 2014; Kensler et al., 2011; Seidman and Seidman, 2000; van Dijk et al., 2014). There is good evidence that domains of MyBP-C near the N terminus bind to the regulated actin filament, whereas its C terminus binds to the myosin thick filament backbone (Fig. 2), playing a regulatory role in muscle contraction (Chow et al., 2014; Kensler et al., 2011; van Dijk et al., 2014). MyBP-C is in the A-band region of the sarcomere in close proximity to the myosin heads (Fig. 2). Another regulator, the giant molecule titin (Granzier and Irving, 1995; LeWinter and Granzier, 2013, 2014), extends through the A-band region, running from the Z-disc, to which actin filaments are bound, to the M-line, the center of the sarcomere. Thus, each half sarcomere has titin molecules running its entire length, where the titin plays an important role in passive tension of the sarcomere (Granzier and Irving, 1995) as well as other roles (LeWinter and Granzier, 2014).
A recent report made the suggestion that MyBP-C and/or other proteins in the vicinity of the myosin heads may play a role in sequestering some of the heads and taking them out of the functionally available pool, reducing Nt and thus Fensemble (Spudich, 2015). The concept of MyBP-C removing myosin heads from the functioning pool of heads in the sarcomere has been suggested previously, with evidence for binding of MyBP-C to S2 and the RLC (for reviews, see Kampourakis et al., 2014; Moss et al., 2015). But there may be a site on the motor domain of S1, which has previously been overlooked, that participates in such sequestration of myosin heads. This site has been called the myosin mesa, which is highly conserved among the cardiac myosins, from mouse α-cardiac to human β-cardiac myosin (Spudich, 2015). The mesa has many more arginine residues on its surface than lysine residues, the opposite of usual protein surfaces (Warwicker et al., 2014). Arginines are known to play a role in transient interactions between different proteins (Jones et al., 2000). Thus, the cluster of eight arginine residues on the mesa, R169, R204, R249, R403, R442, R453, R652, and R663, could be involved in transient interactions between the mesa and another protein or protein domain (e.g. MyBP-C, titin, myosin S2) (Fig. 7, blue-labeled amino acids). Strikingly, all eight of these arginines are sites of HCM mutations (Alfares et al., 2015). A number of other non-arginine cardiomyopathy mutations are also on the mesa in the vicinity of these arginines (Fig. 7). Besides a potential MyBP-C interaction with the myosin mesa, titin could be another player in such an interaction. Indeed, Granzier and colleagues reported that certain titin domains in the A-band of the sarcomere have conserved surface patterns and show weak interaction with myosin S1 (Muhle-Goll et al., 2001).
An intriguing hypothesis is that the myosin mesa HCM mutations reduce the affinity of S1's putative binding partner(s) (e.g. MyBP-C, titin, myosin S2), releasing those heads to now be involved in the contractile process. This would result in hypercontractility of the muscle, which is characteristic of HCM clinically. Because the myosin motor domain is highly allosteric and there may be other binding sites for the putative interacting partner, this molecular mechanism for HCM hypercontractility may extend to other HCM mutations as well, and this mechanism could be a unifying hypothesis as to why HCM mutations are hypercontractile clinically.
Conclusion and future perspectives
Our laboratory is focused on changes in biochemical and biomechanical parameters in HCM and DCM mutant forms of human β-cardiac myosin. Our studies use both the two-component human system of actin and myosin (Aksel et al., 2015; Sommese et al., 2013b) and the six-component reconstituted human system: actin, myosin, Tm, TnC, TnI, and TnT (Gupte et al., 2015; Sommese et al., 2013a). From the considerations described here and elsewhere (Spudich, 2015), it is possible that many of the HCM mutations in the motor domain of myosin alter the effects of a putative MyBP-C, titin or myosin S2 interaction with the mesa surface. Thus, reconstitution of the eight-component system is likely to be necessary to fully understand the effects of the HCM mutations. This may equally apply to the DCM mutations.
Similarly, the effects of small molecule activators and inhibitors on the human cardiac ventricular system (e.g. Malik et al., 2011) will likely have to be understood at the eight-component level in molecular studies to correlate effects seen in the reconstituted system with those observed in skinned fibers, cardiomyocytes, the whole organ, and animals.
